Electronic external gauge K330S, 0~30 / 0,001 / 114 mm / chisel R 0.4 mm

€ 448.00 *Prices are exclusive of VAT

Article code: K330S

0 star(s) in 0 review(s) Write a review

measuring range: 0~30 mm
measuring range: 30 mm
mechanical stroke: 0~30.5 mm
adjustable resolution: 0,001 / 0,002 / 0,005 / 0,01 / 0,02 / 0,05 mm
max. permissible errors G: ± 0.04 mm
repeatability: 0.02 mm
measuring force: 0.9~1.6 N
measuring depth: Lmax = 114 mm
type of measuring contact: chisel R 0.4 mm
mMeasuring contact movable Hb / fixed Hf: 24,7/24,6 mm
functions:
* Zero / Absolute mode / Relative mode
* Min / Max / Hold
* Tolerance
* mm / inch
protection level: IP67
power supply: 2x LR03 (AAA)
data logger (100 measurement values)
reference temperature: 20°C
working temperature: -10~50°C
weight: 430 g
