Sensor N1.6 for Minitest 2500-4500

€ 1,082.00 *Prices are exclusive of VAT

Manufacturer: ElektroPhysik
Article code: 80-0A9-1000

0 star(s) in 0 review(s) Write a review

Sensor N20 for Minitest 2500-4500 for the non-destructive coating thickness measurement of insulating coatings (varnish, enamel, synthetic material etc.) on conductive substrates (aluminium, copper, austenitic stainless steel).

Technical specification

measuring range: 0~20 mm
low range resolution: 10 μm
typical field of application: for measurement of insulating coatings, e. g. rubber, plastics, glass on non-ferrous metal
measuring principle: eddy current
accuracy: ± (1 % of reading + 50 μm)
minimum curvature radius convex: 25 mm
minimum curvature radius concave: 100 mm
minimum measuring area: Ø 70 mm
minimum substrate thickness: 50 µm
dimensions: (ØxL): 66x74 mm

Standard delivery

probe N20
calibration set with calibration standards and zero reference plate(s)
